# Fundamentals of Statistical Testing
### Dr Milan Valášek
### 24 January 2022

---

## Housekeeping

- Welcome from Jennifer and Milan

- Familiarise yourself with Canvas and AnD website

- Come to practicals and bring laptops

- Help desk sessions from this week (sign up on Canvas)

- More info in this week's practical

<br>

- **It won't be easy so do put in the hours!**

---

## Overview

- Recap on distributions

- More about the normal distribution

- Sampling

- Sampling distribution

- Standard error

- Central Limit Theorem

---

## Objectives

After this lecture you will understand

- that there exist mathematical functions that describe different distributions

- what makes the normal distribution normal and what are its properties

- how random fluctuations affect sampling and parameter estimates

- the function of the sampling distribution and the standard error

- the Central Limit Theorem

&nbsp;

.center[**With this knowledge you'll build a solid foundation for understanding all the statistics we will be learning in this programme!**]

---

## It's all Greek to me!

- `$\mu$` is the *population* mean

- `$\bar{x}$` is the *sample* mean

- `$\hat{\mu}$` is the **estimate** of the *population* mean

- Same with *SD*: `$\sigma$`, `$s$`, and `$\hat{\sigma}$`

- Greek is for populations, Latin is for samples, hat is for population estimates

---

## Recap on distributions

- Numerically speaking, the number of observations per each value of a variable
- Which values occur more often and which less often
- The shape formed by the bars of a bar chart/histogram

```r
df <- tibble(eye_col = sample(c("Brown", "Blue", "Green", "Gray"), 555,
                        replace = T, prob = c(.55, .39, .04, .02)),
             age = rnorm(length(eye_col), 20, .65))

p1 <- df %>%
  ggplot(aes(x = eye_col)) +
  geom_bar(fill = c("skyblue4", "chocolate4", "slategray", "olivedrab"), colour=NA) +
  labs(x = "Eye colour", y = "Count")

p2 <- df %>%
  ggplot(aes(x = age)) +
  geom_histogram() +
  stat_density(aes(y = ..density.. * 80), geom = "line", color = theme_col, lwd = 1) +
  labs(x = "Age (years)", y = "Count")

plot_grid(p1, p2)
```


---

## Known distributions

- Some shapes are "algebraically tractable", <i>e.g.</i>, there is a maths formula to draw the line
- We can use them for statistics

```r
df <- tibble(x = seq(0, 10, length.out = 100),
             norm = dnorm(scale(x), sd = .5),
             chi = dchisq(x, df = 2) * 2,
             t = dt(scale(x), 5, .5),
             beta = (dbeta(x / 10, .5, .5) / 4) - .15)

cols <- c("#E69F00", "#56B4E9", "#009E73", "#CC79A7")
df %>%
  ggplot(aes(x = x)) +
  geom_line(aes(y = norm), color = cols[1], lwd = 1) +
  geom_line(aes(y = chi), color = cols[2], lwd = 1) +
  geom_line(aes(y = t), color = cols[3], lwd = 1) +
  geom_line(aes(y = beta), color = cols[4], lwd = 1) +
  labs(x = "x", y = "Density")
```


---

## The normal distribution

- AKA Gaussian distribution, The bell curve

- The one you **need to** understand

- Symmetrical and bell-shaped

- _Not every_ symmetrical bell-shaped distribution is normal!

- It's also about the proportions

- The normal distribution has fixed proportions and is a function of two parameters, `$\mu$` (mean) and `$\sigma$` (or _SD_; standard deviation)

---

## The normal distribution

- Peak/centre of the distribution is its mean (also mode and median)
- Changing mean (**centring**) shifts the curve left/right
- *SD* determines steepness of the curve (small `$\sigma$` = steep curve)
- Changing *SD* is also known as **scaling**

---

### Area below the normal curve

- No matter the particular shape of the given normal distribution, the proportions with respect to *SD* are the same
    - **&sim;68.2%** of the area below the curve is within **&plusmn;1 *SD*** from the mean
    - **&sim;95.4%** of the area below the curve is within **&plusmn;2 *SD*** from the mean
    - **&sim;99.7%** of the area below the curve is within **&plusmn;3 *SD*** from the mean
- We can calculate the proportion of the area with respect to any two points

```r
quantiles <- tibble(x1 = -(1:3), x2 = 1:3, y = c(.21, .12, .03))
tibble(x = seq(-4, 4, by = .1), y = dnorm(x, 0, 1)) %>%
  ggplot(aes(x, y)) +
  geom_density(stat = "identity", color = default_col) +
  geom_density(data = ~ subset(.x, x <= quantiles$x1[3]),
               stat = "identity", color = default_col, fill = default_col) +
  geom_density(data = ~ subset(.x, x >= quantiles$x2[3]),
               stat = "identity", color = default_col, fill = default_col) +
  geom_density(data = ~ subset(.x, x >= quantiles$x1[2] & x <= quantiles$x2[2]),
               stat = "identity", color = NA, fill = second_col) +
  geom_density(data = ~ subset(.x, x >= quantiles$x1[1] & x <= quantiles$x2[1]),
               stat = "identity", color = NA, fill = theme_col) +
  geom_segment(data = quantiles,
               aes(x = x1, xend = x2, y = y, yend = y),
               arrow = arrow(length = unit(0.2, "cm"), angle = 15,
                             type = "closed", ends = "both"),
               color = c(bg_col, default_col, default_col)) +
  geom_line(data = tibble(x = rep(c(-1, 1), 2), y = rep(c(.12, .03), each = 2)),
            aes(x, y, group = y), color = bg_col) +
  geom_line(data = tibble(x = rep(c(-(2:3), 2:3), each = 2),
                          y = as.vector(rbind(0, rep(quantiles$y[-1] + .005, 2)))),
            aes(x, y, group = x), lty = 2, color = default_col) +
  annotate("text", x = rep(0, 3), y = quantiles$y + .05,
           label = c("68.2%", "95.4%", "99.7%"), color = bg_col) +
  labs(x = "z-score", y = "Density") +
  scale_x_continuous(breaks = -4:4)
```


---

### Area below the normal curve

- Say we want to know the number of *SD*s from the mean beyond which lie the outer 5% of the distribution

```r
quantiles <- qnorm(.025) * c(-1, 1)
tibble(x = sort(c(quantiles, seq(-4, 4, by = .1))), y = dnorm(x, 0, 1)) %>%
  ggplot(aes(x, y)) +
  geom_line(color = default_col) +
  geom_density(data = ~ subset(.x, x >= quantiles[1]),
               stat = "identity", color = NA, fill = second_col) +
  geom_density(data = ~ subset(.x, x <= quantiles[2]),
               stat = "identity", color = NA, fill = second_col) +
  geom_line(data = tibble(x = rep(quantiles, each = 2), y = c(0, .15, 0, .15)),
            aes(x, y, group = x), lty = 2, color = default_col) +
  geom_segment(data = tibble(x = quantiles, xend = c(4, -4),
                             y = c(.15, .15), yend = c(.15, .15)),
               aes(x = x, xend = xend, y = y, yend = yend),
               arrow = arrow(length = unit(0.2, "cm"), angle = 15, type = "closed"),
               color = default_col) +
  annotate("text", x = c(-2.8, 2.8), y = .18, label = ("2.5%"), color = default_col) +
  labs(x = "z-score", y = "Density")
```


```r
qnorm(p = .025, mean = 0, sd = 1) # lower cut-off
```

```
## [1] -1.959964
```

```r
qnorm(p = .975, mean = 0, sd = 1) # upper cut-off
```

```
## [1] 1.959964
```
]

---

### Critical values

- If *SD* is known, we can calculate the cut-off point (critical value) for **any proportion** of normally distributed data

```r
qnorm(p = .005, mean = 0, sd = 1) # lowest .5%
```

```
## [1] -2.575829
```

```r
qnorm(p = .995, mean = 0, sd = 1) # highest .5%
```

```
## [1] 2.575829
```

```r
# most extreme 40% / bulk 60%
qnorm(p = .2, mean = 0, sd = 1)
```

```
## [1] -0.8416212
```

```r
qnorm(p = .8, mean = 0, sd = 1)
```

```
## [1] 0.8416212
```
]

- Other known distributions have different cut-offs but the principle is the same

---

.pollEv[
<iframe src="https://embed.polleverywhere.com/discourses/IXL29dEI4tgTYG0zH1Sef?controls=none&short_poll=true" width="800px" height="600px"></iframe>
]

---

## Sampling from distributions

- Collecting data on a variable = randomly sampling from distribution

- The underlying distribution is often assumed to be normal

- Some variables might come from other distributions

- Reaction times: *log-normal* distribution

  - Number of annual casualties due to horse kicks: *Poisson* distribution

  - Passes/fails on an exam: *binomial* distribution

---

## Sampling from distributions

- Samples from the same population differ from one another

```r
# draw a sample of 10 from a normally distributed
# population with mean 100 and sd 15
rnorm(n = 6, mean = 100, sd = 15)
```

```
## [1] 101.61958  80.95560  89.62080  96.04378 106.40106  86.21514
```

```r
# repeat
rnorm(6, 100, 15)
```

```
## [1]  80.31573 107.63193  85.82520  99.95288  93.55956  74.73945
```

---

## Sampling from distributions

- Statistics ( `$\bar{x}$`, `$s$`, <i>etc.</i>) of two samples will be different

- **Sample** statistic (<i>e.g.</i>, `$\bar{x}$`) will likely differ from the **population** parameter (<i>e.g.</i>, `$\mu$`)

```r
sample1 <- rnorm(50, 100, 15)
sample2 <- rnorm(50, 100, 15)

mean(sample1)
```

```
## [1] 98.56429
```

```r
mean(sample2)
```

```
## [1] 105.4175
```

---

## Sampling from distributions

- Statistics ( `$\bar{x}$`, `$s$`, <i>etc.</i>) of two samples will be different

- **Sample** statistic (<i>e.g.</i>, `$\bar{x}$`) will likely differ from the **population** parameter (<i>e.g.</i>, `$\mu$`)

```r
p1 <- ggplot(NULL, aes(x = sample1)) +
  geom_histogram(bins = 15) +
  geom_vline(xintercept = mean(sample1), color = second_col, lwd = 1) +
  labs(x = "x", y = "Frequency") + ylim(0, 8)
p2 <- ggplot(NULL, aes(x = sample2)) +
  geom_histogram(bins = 15) +
  geom_vline(xintercept = mean(sample2), color = second_col, lwd = 1) +
  labs(x = "x", y = "") + ylim(0, 8)

plot_grid(p1, p2)
```


---

## Sampling distribution

- If we took all possible samples of a given size (say *N = 50*) from the population and each time calculated `$\bar{x}$`, the means would have their own distribution

- This is the **sampling distribution** of the mean

- Approximately **normal**

  - Centred around the **true population mean**, `$\mu$`

- Every statistic has its own sampling distribution (not all normal though!)

---

## Sampling distribution

```r
x_bar <- replicate(100000, mean(rnorm(50, 100, 15)))
mean(x_bar)
```

```
## [1] 99.99395
```

```r
ggplot(NULL, aes(x_bar)) +
  geom_histogram(bins = 51) +
  geom_vline(xintercept = mean(x_bar), col = second_col, lwd = 1) +
  labs(x = "Sample mean", y = "Frequency")
```


---

.pollEv[
<iframe src="https://embed.polleverywhere.com/discourses/IXL29dEI4tgTYG0zH1Sef?controls=none&short_poll=true" width="800px" height="600px"></iframe>
]

---

## Standard error

- Standard deviation of the sampling distribution is the **standard error**

```r
sd(x_bar)
```

```
## [1] 2.122072
```

- Sampling distribution of the mean is *approximately normal*: *~68.2% of means of samples* of size 50 from this population will be *within &plusmn;2.12 of the true mean*

---

## Standard error

- Standard error can be **estimated** from any of the samples
<m>$$\widehat{SE} = \frac{SD}{\sqrt{N}}$$</m>

```r
samp <- rnorm(50, 100, 15)
sd(samp)/sqrt(length(samp))
```

```
## [1] 1.872102
```

```r
# underestimate compared to actual SE
sd(x_bar)
```

```
## [1] 2.122072
```
]

- If ~68.2% of sample means lie within &plusmn;1.87, then there's a ~68.2% probability that `$\bar{x}$` will be within &plusmn;1.87 of `$\mu$`

```r
mean(samp)
```

```
## [1] 98.22903
```
]

---

## Standard error

- *SE* is calculated using *N*: there's a relationship between the two

```r
tibble(x = 30:500, y = sd(samp)/sqrt(30:500)) %>%
  ggplot(aes(x, y)) +
  geom_line(lwd=1, color = second_col) +
  labs(x = "N", y = "SE") +
  annotate("text", x = 400, y = 2.5,
           label = bquote(sigma==.(round(sd(samp), 1))),
           color = default_col, size = 6)
```


---

## Standard error

- That is why *larger samples are more reliable*!

---

## Standard error

- Allows us to gauge the _resampling accuracy_ of parameter estimate (<i>e.g.,</i> `$\hat{\mu}$`) in sample

- The smaller the *SE*, the more confident we can be that the parameter estimate ( `$\hat{\mu}$` ) in our sample is close to those in other samples of the same size

- We don't particularly care about our specific sample: we care about the population!

---

## The Central Limit Theorem

- Sampling distribution of the mean is *approximately normal*

- True no matter the shape of the population distribution!

- This is the [Central Limit Theorem](https://en.wikipedia.org/wiki/Central_limit_theorem)

- *"Central"* as in *"really important"* because, well, it is!

---

## CLT in action

---

## CLT in action

---

## Approximately normal

- As *N* gets larger, the sampling distribution of `$\bar{x}$` tends towards a normal distribution with **mean = `$\mu$`** and_ `$SD = \frac{\sigma}{\sqrt{N}}$` _

```r
par(mfrow=c(2, 2), mar = c(3.1, 4.1, 3.1, 2.1), cex.main = 2)
pop <- tibble(x = runif(100000, 0, 1)) %>%
  ggplot(aes(x)) +
  geom_histogram(bins = 25) +
  geom_vline(aes(xintercept = mean(x)), lwd = 1, color = second_col) +
  labs(title = "Population", x = "", y = "Frequency")

plots <- list()
n <- c(5, 30, 1000)
ylab <- c("", "Frequency", "")
for (i in 1:3) {
plot_tib <- tibble(x = replicate(1000, mean(runif(n[i], 0, 1))))
plots[[i]] <- ggplot(plot_tib, aes(x)) +
  geom_histogram(aes(y = ..density..), bins = 30) +
  labs(title = bquote(paste(
    italic(N)==.(n[i]),
    "; ",
    italic(SE)==.(round(sd(plot_tib$x), 2)))),
    x = "", y = ylab[i]) +
  # xlim(0:1) +
  stat_density(geom = "line", color = second_col, lwd = 1)
}

plot_grid(pop, plots[[1]], plots[[2]], plots[[3]])
```


---

.pollEv[
<iframe src="https://embed.polleverywhere.com/discourses/IXL29dEI4tgTYG0zH1Sef?controls=none&short_poll=true" width="800px" height="600px"></iframe>
]

---

## Take-home message

- *Distribution* is the number of observations per each value of a variable

- There are many mathematically well-described distributions

- Normal (Gaussian) distribution is one of them

- Each has a formula allowing the calculation of the probability of drawing an arbitrary range of values

---

## Take-home message

- Normal distribution is
  - **continuous**
  - **unimodal**
  - **symmetrical**
  - **bell-shaped**
  - _it's the right proportions that make a distribution normal!_

- In a normal distribution it is true that
    - **&sim;68.2%** of the data is within **&plusmn;1 *SD*** from the mean
    - **&sim;95.4%** of the data is within **&plusmn;2 *SD*** from the mean
    - **&sim;99.7%** of the data     is within **&plusmn;3 *SD*** from the mean

- Every known distribution has its own _critical values_

---

## Take-home message

- Statistics of random samples differ from parameters of a population

- As *N* gets bigger, sample statistics approaches population parameters

- Distribution of sample parameters is the **sampling distribution**

- **Standard error** of a parameter estimate is the *SD* of its sampling distribution

- Provides *margin of error* for estimated parameter

- The larger the sample, the less the estimate varies from sample to sample

---

## Take-home message

- **Central Limit Theorem**

- Really important!

- Sampling distribution of the mean tends to normal even if population distribution is not normal

- Understanding distributions, sampling distributions, standard errors, and CLT it *most of what you need* to understand all the stats techniques we will cover

---

class: last-slide
background-image: url("/lectures_assets/end.jpg")
background-size: cover
